CNC Stone Countertop Processing Center

HLCNC-3319  is a CNC milling and edge polishing centre designed for contouring, cutting and turning with three interpolated axis offering users the possibility of multiple and complex machining operations which would otherwise require several machines.  It's suitable for processing all kind of stone slab coutertop, such as kithen countertop, bath countertop, cabinet countertop, bar counter, table,  windowsill,  door sets etc.   Relief engraving like stone background wall relief, European style edging etc. is available too.

TECHNICAL DATA
Model Number		HLCNC-3015	HLCNC-3319	HLCNC-1308
Stroke (X-axis)	mm	3040	3500	1340
Stroke (Y-axis)	mm	1540	1950	840
Stroke (Z-axis)	mm	320	320	320
Power of motor	kw	7.5	7.5	7.5
Rotating speed	rpm	0-8000	0-8000	0-24000
Tool holder model	BT	40	40	40
Tool-store position	nr	12	20	11
Workbench dimension	mm	3000x1500	3300x1900	1300x800
Gross Weight	kg	4000	5000	2500
Demension (L x W x H)	cm		553x320x230

Main Features
1) Powered by numerical control planning and interfaced with our CAD / CAM software, their automatic tools allow for calibration, milling, carving, honing and polishing slabs continuously and automatically in one go.
2) Bilateral tools-store with 20 stations for automatic tool change
3) Crossbeam and carling adopt Taiwan's Hiwin linear guide to move, which ensure high precision of cutting and long life.
4) X/Y axis with dust colletor,keep machine cleanly,prolong useful-life
5 )3 axis Yaskawa servo driver,high speed, high efficiency, fine cutting without serrated ripple, smooth bottom plane,clear outline.
6) With vacuum cups and aluminum alloy lock to double holding the working pieces, avoiding even little displacement

7) Equipped with USB interface for operator to input and output program conveniently.
8) High speed and low noise.
9) High efficiency and low processing cost.
